Sunhope’s Aluminum Brazing Furnace is an advanced industrial system engineered for high-efficiency, precision brazing of aluminum components. Designed with a nitrogen protection atmosphere and low gas consumption, it ensures exceptional performance across automotive, HVAC, aerospace, and other manufacturing sectors. With intelligent PLC control and a robust continuous tunnel structure, this furnace guarantees reliability, energy savings, and superior brazing quality.
Parameter | Specification |
---|---|
Rated Power | 103.45KW |
Power Supply | AC380V, Three-Phase, 50Hz |
Brazing Temperature | 600–650°C |
Mesh Belt Speed | 200–1500 mm/min (continuously adjustable) |
Nitrogen Purity | ≥99.9995% |
Mesh Belt Face Height | 900mm |
Heating Method | Radiant Tube Heating / Plug-in Elements |
Cooling Method | Air Cooling |
Heating Time | 2–3 minutes |
Workpiece Max Height | 250mm |
Ideal for brazing:
For over 15 years, SUNHOPE has been a leading manufacturer and developer specializing in automotive radiator and condenser components, exporting globally. Our expertise encompasses the entire radiator production line.
